HP Pro x2 612 G2 - Page 53

1. Left speaker
2. WLAN card antennas
3. Smart card
NOTE: The display cable and touch control cable are still connected to the display and system board.
Separate the middle frame and display only enough to disconnect the cables.
6. Insert a thin tool (1) in the video cable cutout, and then move the display panel (2) away from the middle
frame.
Component replacement procedures 47
