System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Table 6-15 System board descriptions and part numbers
Description Spare part number
System board for use in models with discrete graphics memory:
● Intel Core i7-8665U processor L58729-xx1
● Intel Core i7-8565U processor L58728-xx1
● Intel Core i5-8365U processor L58727-xx1
● Intel Core i5-8265U processor L58726-xx1
System board for use in models with UMA graphics memory:
● Intel Core i7-8665U processor, models with a WWAN module L58735-xx1
● Intel Core i7-8565U processor, models with a WWAN module L58734-xx1
● Intel Core i5-8365U processor, models with a WWAN module L58733-xx1
● Intel Core i5-8265U processor, models with a WWAN module L58731-xx1
● Intel Core i5-8265U processor L58732-xx1
● Intel Core i3-8145U processor, models with a WWAN module L58736-xx1
● Intel Core i3-8145U processor L58730-xx1
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 34).
2. Remove the following components:
a. Bottom cover (see Bottom cover on page 35)
b. Battery (see Battery on page 36)
c. Optical drive (see Optical drive on page 39)
d. Hard drive (see Hard drive on page 40)
e. Solid-state drive or Optane memory module (see Solid-state drive on page 42)
f. WWAN module and bracket (see WWAN module on page 43)
g. WLAN module (see WLAN module on page 45)
h. Memory module (see Memory on page 37)
i. Keyboard (see Keyboard on page 47)
Component replacement procedures 69
