Fingerprint reader assembly
Table 6-17 Fingerprint reader assembly descriptions and part numbers
Description Spare part number
Fingerprint reader assembly (includes cable and gasket) L58718-001
Fingerprint reader bracket (included in Bracket Kit) L59054-001
Before removing the ngerprint reader assembly, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 34).
2. Remove the following components:
a. Bottom cover (see Bottom cover on page 35)
b. Battery (see Battery on page 36)
c. Optical drive (see Optical drive on page 39)
d. Hard drive (see Hard drive on page 40)
e. Solid-state drive or Optane memory module (see Solid-state drive on page 42)
f. WWAN module and bracket (see WWAN module on page 43)
g. Keyboard (see Keyboard on page 47)
h. Internal frame (see Internal frame on page 51)
i. Serial port board or VGA port board (see Serial port board or VGA port board on page 66).
j. System board (see System board on page 69)
Remove the ngerprint reader assembly:
1. Remove the Phillips M2.0 × 2.0 screw (1) from the ngerprint reader bracket.
2. Slide the bracket, and then lift the bracket o the ngerprint reader board (2).
74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
