The HP ProCurve Switch 5406zl-48G Intelligent Edge (J8699A), 5412zl-96G Intelligent Edge (J8700A),
5406zl-48G-PoE+ (J9447A), and 5412zl-96G-PoE+ (J9448A) are preconfigured bundles that offer a pretested
environment and a lower-cost starter switch to which additional modules can be added. The major components
of these preconfigured bundles are the following:
5406zl-48G-PoE+ 5412zl-96G-PoE+
6-slot chassis 12-slot chassis
1 management module 1 management module
44 10/100/1000 PoE ports 92 10/100/1000 PoE ports
4 Mini-GBIC ports 4 Mini-GBIC ports
4 open slots 8 open slots
1 fan tray (2 fans) 1 fan tray (4 fans)
1 internal 1500 W PoE+ power supply 2 internal 1500 W PoE+ power supplies
1 open power-supply slot 2 open power-supply slots
Intelligent Edge software Intelligent Edge software
5400zl series chassis layout
The HP ProCurve Switch 5406zl chassis is rack-mountable with a 4U height, and the Switch 5412zl chassis is
rack-mountable with a 7U height. The line interface modules are inserted in the front slots, labeled A through F
on the 5406zl, and A through L on the 5412zl.
The management module is removable/replaceable and occupies a dedicated slot in the front. The switch does
not have to be powered-off to remove the management module.
However, when the management module is removed, all ports lose communication and the system will be
powered down.
Table 2. PoE+ switch preconfigured bundle components
5406zl-48G Intelligent Edge 5412zl-96G Intelligent Edge
6-slot chassis 12-slot chassis
1 management module 1 management module
48 10/100/1000 PoE ports 96 10/100/1000 PoE ports
4 open slots 8 open slots
1 fan tray (2 fans) 1 fan tray (4 fans)
1 internal 875 W power supply 2 internal 875 W power supplies
1 open power-supply slot 2 open power-supply slots
Intelligent Edge software Intelligent Edge software
Table 1. Intelligent Edge switch preconfigured bundle components
