29
Power supply
configuration
Total PoE
power (watts)
Number of PoE ports at 15.4 W Number of PoE ports at 8 W
No redundancy With 1+1 redundancy No redundancy With 1+1 redundancy
1—875 W (J8712A) 273 17 N/A 34 N/A
2—875 W (J8712A) 546 35 17 68 34
1—1500 W (J8713A) 900 58 N/A 112 N/A
2—1500 W (J8713A) 1800 116 58 144* 112
4—1500 W** (J8713A) 3600 144* 114 144* 144*
* Switch 8206zl and 5406zl fully loaded with 6 modules provides up to 144 ports
** Using the HP ProCurve Switch zl Power Supply Shelf
Table 4. Examples of maximum number of PoE ports for Switch 8212zl and 5406zl
Power supply
configuration
Total PoE
power (watts)
Number of PoE+ ports at 30 W Number of PoE ports at 15.4 W
No redundancy With 1+1 redundancy No redundancy With 1+1 redundancy
1—1500 W PoE+
@ 110 V (J9306A)
300 10 N/A 19 N/A
2—1500 W PoE+
@ 110 V (J9306A)
600 20 10 38 19
1—1500 W PoE+
@ 220 V (J9306A)
900 30 N/A 58 N/A
2—1500 W PoE+
@ 220 V (J9306A)
1800 60 30 116 58
4—1500 W PoE+**
@ 110 V (J9306A)
1200 40 20 77 38
4—1500 W PoE+**
@ 220 V (J9306A)
3600 72*** 60 144* 116
* Switch 8206zl and 5406zl fully loaded with 6 modules provides up to 144 ports
** Using the HP ProCurve Switch zl Power Supply Shelf
*** Number of PoE+ ports is limited to a maximum of 12 per slot (72 ports in 6-slot chassis)
Table 5. Examples of maximum number of PoE+ and PoE ports for Switch 8212zl and 5406zl
Tables 4 and 5 show examples of the maximum number of PoE or PoE+ ports that can be supported by the
Switch 8206zl and 5406zl. Table 4 shows the maximum number of PoE ports at full power (Class 0—15.4
watts), and the next section shows the maximum number of PoE ports at phone power (8 watts) for each
configuration. Table 5 shows the maximum number of PoE+ ports at full power (Class 4—30 watts), and
the next section shows the maximum number of PoE ports at full power (Class 0—15.4 watts) for each
configuration. These categories are further subdivided based on whether a second internal power supply is
used to provide power redundancy in the event one of the power supplies fails.
NOTE: Two 875 W internal power supplies cannot supply sufficient PoE power to a Switch 8206zl and 5406zl
fully populated with 24-port line interface modules (144 ports). Two 1500 W power supplies can be used to
supply full PoE power (15.4 watts) to 116 ports.
