33
•J8177CHPProCurveGigabit1000Base-TMini-GBIC
•J9142BHPProCurve1000-BX-DSFP-LCMini-GBIC
•J9143BHPProCurve1000-BX-USFP-LCMini-GBIC
•J9099BHPProCurve100-BX-DSFP-LCTransceiver
•J9100BHPProCurve100-BX-USFP-LCTransceiver
•J9054BHPProCurve100-FXSFP-LCTransceiver
Description
This interface module has 24 mini-GBIC ports and is appropriate for use as an aggregator in a distribution
environment. This module supports the same mini-GBICs as the HP ProCurve Switch zl 20-Port 10/100/1000 +
4-Port Mini-GBIC Module previously described. The mini-GBICs are ordered separately.
Ports
24 open mini-GBIC slots
Mini-GBICs supported (ordered separately)
•J4858CHPProCurveGigabit-SX-LCMini-GBIC
•J4859CHPProCurveGigabit-LX-LCMini-GBIC
•J4860CHPProCurveGigabit-LH-LCMini-GBIC
•J8177CHPProCurveGigabit1000Base-TMini-GBIC
•J9142BHPProCurve1000-BX-DSFP-LCMini-GBIC
•J9143BHPProCurve1000-BX-USFP-LCMini-GBIC
•J9099BHPProCurve100-BX-DSFP-LCTransceiver
•J9100BHPProCurve100-BX-USFP-LCTransceiver
•J9054BHPProCurve100-FXSFP-LCTransceiver
HP ProCurve Switch zl 24-Port Mini-GBIC Module (J8706A)
Description
This interface module has 4 10-GbE X2 transceiver ports that support any combination of SR, LR, ER, or CX4
transceiver types. This module provides maximum flexibility for connecting 10-GbE high-speed downlinks to
any other switch supporting that connection type. The wide variety of distances supported makes this module
an ideal choice for intra-building connections. Ports can be trunked to provide higher throughput. Two such
modules can have their ports trunked across both modules to provide module redundancy as well.
HP ProCurve Switch zl 4-Port 10-GbE X2 Module (J8707A)
