HP ProDesk 400 G2 Quickspecs

HP BIOSphere
Key features of the HP BIOS include:
Deployment and manageability - HP BIOS provides several technologies that help integrate the HP ProDesk 400 G2 MT
Business PC into the enterprise, such as PXE, and F10 Setup support for 12 languages.
Support UEFI specification 2.3.1
Thermal and power management - The HP BIOS provides and enables thermal and power management technologies so
component temperatures are managed for high reliability and to assist in operating the HP Business Desktop computer in
any enterprise environment.
Thermal Controlled Fans - Automatic or manual controlled fan speeds for cooling and acoustic performance Serviceability -
HP BIOS provides diagnostic and detailed service information.
Upgrades and recovery - HP BIOS provides numerous ways to upgrade HP Business Desktop computers, including BIOS
updates from within DOS (DOSFlash), BIOS updates from within Windows (HPQFlash), HP Client Manager, and fail-safe
recovery (Emergency Boot Block Recovery). In addition, the HP Business Desktop BIOS Utilities tool enables replicated BIOS
setup throughout the Enterprise; it is available from within the BIOS F10 setup and from the support website.
HP BIOS uses PKI signing of the BIOS for trusted BIOS upgrades and recovery.
Serviceability - HP BIOS provides diagnostic and detailed service information.
Additional HP BIOS Features:
Power-On password - Helps prevent an unauthorized user from powering on the system.
Administrator password - Also known as the setup password, this helps prevent unauthorized changes to the system
configuration. If the administrator password is not known, the BIOS version cannot be changed and changes cannot be
made to BIOS settings using F10 setup or under the OS.
Advanced Configuration and Power Interface (ACPI) - Represents a significant innovation in power and configuration
management, allowing operating systems and applications to manage power based on activity and usage. HP Pro models
use ACPI to provide power conservation features.
S5 Max Power Savings setting supports EU Lot6 requirement and allows the computer to power down below 1W is S5
(when turned off). When S5 Max Power Savings feature is enabled power to slots is turned off along with WOL functionality.
Master Boot Record Security - Helps to prevent changes and/or infections to the Master Boot Record caused by viruses or
malicious code.
HP BIOS Protection - prevents unauthorized updates or changes to the BIOS due to malware, viruses, or malicious BIOS
updates. Based on NIST SP800-147 policy guidelines.
QuickSpecs
HP ProDesk 400 G2 Microtower Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14982 North America — Version 1 — May 28, 2014 Page 13

HP ProDesk 400 G2 Specifications

General

Tcase	72 °C
Bus type	DMI2
Stepping	C0
Processor cache	2 MB
Processor cores	2
Processor model	G1840
System bus rate	5 GT/s
Processor family	Intel® Celeron® G
Processor series	Intel Celeron Processor G1000 Series for Desktop
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	32-bit, 64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	54, 53 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333 MHz
Memory bandwidth supported by processor (max)	21.3 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 4 GB
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	No
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Power supply	180 W
Product type	PC
Market positioning	Business
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Horizontal
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Scalability	1S
Processor code	SR1VK
Processor ARK ID	80800
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise, Small Business

Weight and Dimensions

Depth	358.8 mm
Width	165 mm
Height	355 mm
Weight	6500 g
