HP ProDesk 400 G2 Quickspecs

Intel HD Graphics
VGA Controller Integrated
DisplayPort Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and Multi-Stream
Technology for a maximum of 2 displays (including the integrated panel)
Bus Type N/A
RAMDAC N/A
Memory Intel graphics do not have dedicated memory but utilizes some of the computer's system memory
The amount of memory used for graphics depending on the amount of system memory installed,
BIOS settings, operating system, and system load. 32 MB is pre-allocated for graphics use at system
boot time. Additional memory can be allocated at boot time by the BIOS for PAVP (Protected Audio
Video Playback) support for playback of protected video content.
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory
Technology (DVMT), to provide an optimal balance between graphics and system memory use.
Maximum Graphics Memory Microsoft Windows 7 Windows 8.1
Up to 1.7GB Up to 1.8GB
NOTE: the actual amount of maximum graphics memory can be less than the amounts listed above
depending upon your computer's configuration.
Maximum Color Depth 32 bits/pixel
Graphics/Video API Support 4th Generation Core processors:
The Processor Graphics contains a refresh of the seventh generation graphics core enabling
substantial gains in performance and lower power consumption. Up to 16 EU support.
Next Generation Intel Clear Video Technology HD Support is a collection of video playback and
enhancement features that improve the end user's viewing experience
Encode/transcode HD content
Playback of high definition content including Blu-ray Disc
Superior image quality with sharper, more colorful images
DirectX Video Acceleration (DXVA) support for accelerating video processing
Full AVC/VC1/MPEG2 HW Decode
Advanced Scheduler 2.0, 1.0
Windows 7, Windows 8.1, Linux OS Support
DirectX 11.1
OpenGL 4.0
Open CL 1.2
Supported Display Resolutions and Refresh Rates
NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
QuickSpecs
HP ProDesk 400 G2 Microtower Business PC
Technical Specifications - Graphics
DA - 14982 North America — Version 1 — May 28, 2014 Page 19

HP ProDesk 400 G2 Specifications

General

Tcase	72 °C
Bus type	DMI2
Stepping	C0
Processor cache	2 MB
Processor cores	2
Processor model	G1840
System bus rate	5 GT/s
Processor family	Intel® Celeron® G
Processor series	Intel Celeron Processor G1000 Series for Desktop
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	32-bit, 64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	54, 53 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333 MHz
Memory bandwidth supported by processor (max)	21.3 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 4 GB
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	No
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Power supply	180 W
Product type	PC
Market positioning	Business
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Horizontal
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Scalability	1S
Processor code	SR1VK
Processor ARK ID	80800
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise, Small Business

Weight and Dimensions

Depth	358.8 mm
Width	165 mm
Height	355 mm
Weight	6500 g
