HP ProDesk 400 G2 Quickspecs

NVIDIA NVS 315 1GB PCIe x 16 Graphics Card
Introduction Get efficient dual-display graphics performance in a PCI Express low-profile graphics card with the
NVIDIA NVS 315 PCIe x16 1 GB Graphics Card, an ideal desktop graphics solution for professional
business and commercial applications.
Performance and Features The NVIDIA® NVS 315 Graphics Card offers 1 GB of ultrafast DDR3 memory and is capable of
supporting up to 2 displays.
DisplayPort connector supports multimode technology to support connection to DVI-D, VGA and
HDMI monitors with optional adapters in kits NR078AA, FH973AT, BP937AA, AS615AA.
For a DisplayPort to DisplayPort connections use the optional DisplayPort Cable Kit VN567AA.
Form Factor Low Profile: 2.713 × 6.15 in
Graphics Controller NVIDIA® NVS 315
Memory Clock 875MHz
Memory Size 512 MB DDR3
Memory Bandwidth 14 GB/s
Connectors DMS-59 , with support for dual VGA, dual DVI or dual Display Port with the appropriate adapter cable
Display Max. Resolution Up to 2048 x 1536 VGA; 1920 x 1200 DVI; 2560 x 1600 DisplayPort
Display Output Up to 2 displays in the following configurations
Dual DVI:
Drives two DVI displays using optional HP DMS59 DVI Dual-
head Connector Cable DL139A
Dual DisplayPort:
Drives two DisplayPort using optional HP DMS-59 to Dual
DisplayPort kit XP688AA
Dual VGA:
Drives two analog using the included HP DMS-59 to Dual
VGA Cable
Supported Display Resolutions and Refresh Rates
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution Maximum Refresh Rates (Hz) by Connection
Analog Connection Digital Connection
640 x 480 85 60
720 x 480 85 60
720 x 576 85 60
800 x 600 85 60
1024 x 768 85 60
1280 x 720 85 60
1280 x 768 85 60
1280 x 1024 85 60
1440 x 900 75 60
1600 x 1024 85 60
1600 x 1200 85 60
QuickSpecs
HP ProDesk 400 G2 Microtower Business PC
Technical Specifications - Graphics
DA - 14982 North America — Version 1 — May 28, 2014 Page 22

HP ProDesk 400 G2 Specifications

General

Tcase	72 °C
Bus type	DMI2
Stepping	C0
Processor cache	2 MB
Processor cores	2
Processor model	G1840
System bus rate	5 GT/s
Processor family	Intel® Celeron® G
Processor series	Intel Celeron Processor G1000 Series for Desktop
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	32-bit, 64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	54, 53 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333 MHz
Memory bandwidth supported by processor (max)	21.3 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 4 GB
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	No
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Power supply	180 W
Product type	PC
Market positioning	Business
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Horizontal
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Scalability	1S
Processor code	SR1VK
Processor ARK ID	80800
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise, Small Business

Weight and Dimensions

Depth	358.8 mm
Width	165 mm
Height	355 mm
Weight	6500 g
