Illustrated Parts Catalog
1-4 HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide
Table 1-1: Mechanical and System Spare Parts List continued
Item Description Spare Part Number
Miscellaneous
14 Replacement battery, 3-V lithium 234556-001
15 Two-device terminated SCSI cable (Ultra3)* 293373-001
16 Hard drive cable kit* 293372-001
a) ATA hard drive cables (2)*
b) Optical device/diskette assembly drive cable*
17 Miscellaneous plastics kit 293374-001
a) Bezel
b) Shipping/ejector key
c) PCI card guide*
d) Bezel screws*
18 Hardware kit 293375-001
a) Hard drive tray
b) Bezel blank
c) Cable support bracket
d) PCI slot cover*
19 Rack mounting kit (fixed rack rails)* 173845-001
20 Return kit* 207732-001
21 Country kit* 293376-001
Option Kit Spares
Remote Insight Lights-Out Edition II* 232386-001
Sliding rails and cable management system kit* 177852-001
Telco rack-mounting kit* 177853-001
Third-party cabinet rack-mounting kit* 177854-001
* Not shown
