Illustrated Parts Catalog
This chapter provides the illustrated parts breakdown and spare parts list for the
HP ProLiant DL320 Generation 2 server. The table in this chapter provides names and
ordering numbers for all referenced spare parts.
Mechanical Parts Exploded View
18b
17a
1
2
18c
17b
18a
Figure 1-1: Mechanical parts exploded view
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 1-1

HP ProLiant DL320 Generation 2 Specifications

General

Memory Slots	4 DIMM slots
Processor	Intel Pentium 4
Network	Integrated 10/100/1000 NIC
Form Factor	1U Rackmount
Operating System Support	Red Hat Linux, SuSE Linux
