HP ProLiant DL320 Generation 2

Removal and Replacement Procedures
Bezel Blank
To remove the bezel blank:
1. Power down the server. See “Powering Down the Server” in this chapter.
2. Remove the shipping/ejector key from the chassis if you have not already done so. See
“Shipping/Ejector Key” in this chapter.
3. Insert the end of the shipping/ejector key approximately 1.25 cm (0.5 in) into the optical
device/diskette drive assembly ejector port on the lower right corner of the server front
panel (1) to eject the blank (2).
Figure 2-3: Removing the bezel blank
To replace the bezel blank, slide the blank into the empty bay until it locks into place. Store
the shipping/ejector key in the chassis or other safe location for future use.
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 2-9
