Removal and Replacement Procedures
6. To install a DIMM, gently push the DIMM into the socket on the system board (1). As
the DIMM enters the socket and is properly seated, the latches close (2).
Figure 2-30: Installing a DIMM in a DIMM socket
CAUTION: Use only HP supplied DIMMs. DIMMs from other sources can adversely affect
data integrity.
7. Press down firmly on the DIMM while pushing the latches inward until the latches snap
into place.
2-36 HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide
