HP ProLiant DL320 Generation 2

Removal and Replacement Procedures
12. Remove the processor. See “Processor” in this chapter.
CAUTION: Always use a new heatsink when replacing processors on the system. Failure to
use new components may result in damage to the processor. See “Processor” in this chapter.
13. Identify the alignment keys and keyhole locations, 1 through 6, on the system board.
Figure 2-35: Identifying system board alignment keys and keyhole
locations
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 2-41
