HP ProLiant DL320 Maintenance And Service Guide

Illustrated Parts Catalog
Mechanical Parts and System Components Spares List
Table 1-1: Mechanical and System Spare Parts List
Item Description Spare Part Number
Mechanical Components
1 Access panel 307130-001
2 Fixed cable tray 173839-001
3 PCI riser board assembly 293365-001
4 Center wall bracket with fans 293366-001
Power
5 180-Watt power supply 293367-001
Boards
6 User interface board 207725-001
7 Optical device/diskette drive assembly backplane 207726-001
8 System board 293368-001
9 a) Single channel, Ultra3 slotless SCSI controller module
b) Support posts (SCSI models only)
293618-001
Processor
10 a) 2.26-GHz Intel® Pentium® 4 processor
b) 2.66-GHz Intel Pentium 4 processor*
(Reserved)
293370-001
326509-001
11 Heatsink 293377-001
Memory
12 a) PC2100 DDR ECC Registered DIMM 128-MB 300691-001
b) PC2100 DDR ECC Registered DIMM 256-MB* 300699-001
c) PC2100 DDR ECC Registered DIMM 512-MB* 300700-001
d) PC2100 DDR ECC Registered DIMM 1-GB* 300701-001
Mass Storage Devices
13 Optical devices/diskette drive assembly
a) CD-ROM/diskette drive assembly 293371-001
b) DVD-ROM/diskette drive assembly* 269046-001
c) ATA hard drive, 80 GB 287685-001
* Not shown
continued
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 1-3
HP CONFIDENTIAL Codename: Moonstar 266 Part Number: 293164-002 Last Saved On: 4/14/03 9:34 AM

HP ProLiant DL320 Specifications

General

Product Line	ProLiant
CPU Type	Intel Xeon
Storage	Up to 4 LFF (3.5") or 8 SFF (2.5") SAS/SATA/SSD drives (depending on model and configuration)
Network	Embedded 1GbE
Power Supply	Single or Redundant Power Supplies (depending on model and configuration)
Form Factor	1U
Server Type	Rack Server
