Illustrated parts catalog 20
Item Description Spare part
number
Customer self repair (on
page
6
)
d) 2.80-GHz Intel Core i3-3220T processor, 2C, 3 MB,
35 W*
701533-001
Optional
2
e) 2.90-GHz Intel Core i3-3240T processor, 2C, 3 MB,
35 W*
701532-001 Optional
2
f) 3.10-GHz Intel Pentium G2120 processor, 2C, 3 MB,
55 W*
703516-001 Optional
2
g) 3.10-GHz Intel Xeon E3-1220V2 processor, 4C, 8
MB, 69 W*
686686-001 Optional
2
h) 3.30-GHz Intel Core i3-3220 processor, 2C, 3 MB,
55 W*
701538-001 Optional
2
i) 3.30-GHz Intel Xeon E3-1230V2 processor, 4C, 8 MB,
69 W*
686685-001 Optional
2
j) 3.40-GHz Intel Core i3-3240 processor, 2C, 3 MB, 55
W*
701537-001 Optional
2
k) 3.40-GHz Intel Xeon E3-1240V2 processor, 4C, 8
MB, 69 W*
686684-001
Optional
2
l) 3.50-GHz Intel Xeon E3-1270V2 processor, 4C, 8 MB,
69 W*
686683-001 Optional
2
m) 3.70-GHz Intel Xeon E3-1290V2 processor, 4C, 8
MB, 87 W*
686681-001 Optional
2
16
System board assembly 686659-001 Optional
2
17
Fan module 686664-001 Mandatory
1
18
LFF drives (8.89 cm, 3.5 in) — —
Non-hot-plug drives, SATA — —
a) 500 GB, 6G hard drive 659571-001 Mandatory
1
b) 1 TB, 6G hard drive* 659569-001 Mandatory
1
c) 2 TB, 6G hard drive* 659570-001 Mandatory
1
d) 3 TB, 6G hard drive* 628183-001 Mandatory
1
Non-hot-plug drives, SAS — —
a) 450 GB, 6G hard drive* 517353-001 Mandatory
1
b) 600 GB, 6G hard drive* 517355-001 Mandatory
1
Hot-plug drives, SATA — —
a) 100 GB, 3G MLC solid state drive* 653968-001 Mandatory
1
b) 200 GB, 3G MLC solid state drive* 653969-001 Mandatory
1
c) 400 GB, 3G MLC solid state drive* 653970-001 Mandatory
1
d) 500 GB, 6G hard drive* 658103-001 Mandatory
1
e) 1 TB, 6G hard drive* 657739-001 Mandatory
1
f) 2 TB, 6G hard drive* 658102-001 Mandatory
1
g) 3 TB, 6G hard drive* 628182-001 Mandatory
1
Hot-plug drives, SAS
—
—
a) 450 GB, 6G hard drive* 653951-001 Mandatory
1
b) 600 GB, 6G hard drive* 653952-001 Mandatory
1
