a. Extend the server from the rack (Extend the server from the rack on page 24).
b. Remove the server from the rack (Remove the server from the rack on page 25).
4. Remove the access panel (Remove the access panel on page 25).
5. Using a Torx T-10 screwdriver, remove the 4 LFF display port/USB blank.
6. Install the 4 LFF display port/USB module.
7. Route and connect the cable.
Hardware options installation 99
