6. Remove the access panel (Remove the access panel on page 25).
7. Remove the serial cable blank.
8. Connect the serial cable option, and then secure the cable with two T-10 screws. Then, remove the
backing from the double-sided tape and press down where indicated.
9. Install the access panel (Installing the access panel on page 25).
10. Install the server in the rack.
11. Connect each power cord to the server.
12. Connect each power cord to the power source.
13. Power up the server (Powering up the server on page 24).
Installing the Chassis Intrusion Detection switch option
Prerequisites
Before installing this option, be sure you have the following:
The components included with the hardware option kit
Installing the Chassis Intrusion Detection switch option 101
