Illustrated Parts Catalog
This chapter provides the illustrated parts breakdown and a spare parts list for
ProLiant ML370 Generation 3 servers. Figure 1-1 shows the mechanical components.
Figure 1-2 shows the system components. Refer to Table 1-1 for the names of referenced
spare parts.
HP ProLiant ML370 Generation 3 Server Maintenance and Service Guide 1-1

HP ProLiant ML370 Specifications

General

Form Factor	Tower
Server Type	Tower Server
Chipset	Intel C600 Series Chipset
Maximum Memory	384 GB
Network Controller	HP Ethernet 1Gb 2-port 330i Adapter or HP FlexibleLOM
Drive Bays	Up to 24 SFF or 18 LFF
Management	HP iLO (Integrated Lights-Out)
Storage Controller	Smart Array
