Removal and Replacement Procedures
Removable Media Blanks
NOTE: HP recommends that you remove or extend the CD-ROM drive to ease
removable media blank removal.
To remove the removable media blanks:
1. Remove the front bezel (tower server only). Refer to “Front Bezel” in this chapter.
2. Remove the access panel. Refer to “Access Panel” in this chapter.
3. Slide the media latch to release the blanks (1) while pushing out the removable media
blanks (2) from behind.
Figure 2-19: Removing the removable media blanks
CAUTION: Always populate drive bays with either a hard drive or blank. Operating the server
without installing a hard drive or blank results in improper airflow and improper cooling that
can lead to thermal damage.
To replace a removable media blank, slide it back into the chassis.
HP ProLiant ML370 Generation 3 Server Maintenance and Service Guide 2-21
