LED Indicators and Switches
Table 4-6: System Board LEDs continued
Item Description Status
7 PPM 2 Amber = Processor or
PPM failed
Off = Normal
8 OSM status Green = OSM enabled
Amber = PSM failed
over
Off = Normal memory
configuration
9 Processor 2 Amber = Processor or
PPM failed
Off = Normal
10 Processor 1
11 PPM 1
12 System overtemperature Amber = System
overtemperature event
Off = Normal
13 iLO Diagnostic LEDs Refer to the iLO User’s
Guide on the
Documentation CD
4-10 HP ProLiant ML370 Generation 3 Server Maintenance and Service Guide
