Rear components

Component Component

1 Security cable slot 6 DisplayPort port

2 Serial port 7 USB Type-A ports (2)

3 PS/2 keyboard connector 8 USB Type-A ports (2)

4 PS/2 mouse connector 9 RJ-45 (network) jack

5 Power connector

4 Chapter 1 Product features
