Processor
Description
Intel Core i7-7700T (2.9-GHz)
Intel Core i5-7600T (2.8-GHz)
Intel Core i3-7500T (2.7-GHz)
Intel Core i3-7300T (3.5-GHz)
Intel Core i3-7100T (3.4-GHz)
Intel Core i7-6700T (2.8-GHz)
Intel Core i5-6600T (2.7-GHz)
Intel Core i5-6500T (2.5-GHz)
Intel Core i3-6100T (3.2-GHz)
Intel Pentium G4600T (3.0-GHz)
Intel Pentium G4560T (2.9-GHz)
Intel Pentium G4400T (2.9-GHz)
Intel Celeron G3930T (2.7-GHz)
Intel Celeron G3900T (2.6-GHz)
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Remove the access panel (see Access panel on page 24).
5. Remove the system board shield (see System board (EMI) shield on page 32).
6. Remove the heat sink (see Heat sink on page 37).
7. Rotate the locking lever to its full open position (1).
38 Chapter 4 Removal and Replacement Procedures
