Top trim
The top trim is located along the top of the computer.
To remove the top trim:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Remove the access panel (see Access panel on page 24).
5. Remove the ve Torx screws that secure the trim to the computer.
6. Rotate the bottom of the trim up and o the computer.
To install the top trim, reverse the removal procedures.
48 Chapter 4 Removal and Replacement Procedures
