2-15
Status
Green Features
Table 2-9. Green Features Status Fields
Field Description
Port Energy Saving Configuration
Auto Port Power-Down The current Auto Port Power-Down setting (Enabled or Disabled). When
enabled, the port is set in power save mode when there is no link.
Low-Traffic Idle (EEE) The current Energy Efficient Ethernet (EEE) setting (Enabled or Disabled). When
enabled, ports that are not passing traffic are powered off until the link partner
indicates the port should power on to receive new data.
Cable Energy Saving Configuration
Cable Length Detect The current Cable Length Detect setting (Enabled or Disabled). When enabled,
port power consumption is adjusted based upon cable length. Short cables use
less power than long cables.
LED Intensity Configuration
LED Intensity The setting (Enabled or Disabled) that indicates if the switch is configured to
change LED intensity levels at certain times of day.
Intensity Level The desired LED intensity level that takes effect if the LED Intensity setting is
enabled. Valid values are High, Medium, Low, or Off. Default value is Off.
Start Time The time of day when the configured LED Intensity Level is activated.
Duration The number of hours the configured LED Intensity Level is in effect.
Recur Daily The current setting (Yes or No) that indicates if the LED intensity levels will
change daily at the configured time.
EEE Interface Status
Interface The port number.
Link Partner Supports EEE Indicates if the link partner supports EEE (Yes or No).
Wakeup Time Negotiated by LLDP Indicates if the EEE wakeup time is negotiated with the link partner (Yes or No).
If No, the Rx Wakeup time and Tx Wakeup time columns display a dash.
Rx Wakeup Time (µSec) The Rx Wakeup time in effect for that port.
Tx Wakeup Time (µSec) The Tx Wakeup time in effect for that port.
