10-9
Maintenance
Dual Image Configuration
Figure 10-16. Password Manager Page
Note There is no default password. Passwords must be at least 8 characters but no more than 64 alpha-
numeric and special characters (~,`,!,@,#,$,%,^,&,*,(,),-,_,+,=,{,[,},],|,\,<,,,>,.,?,/,”,’, and space) in length,
and are case sensitive. The password needs to be entered again to confirm new password. In case of
a forgotten password, manually reset the switch to its factory defaults.
Enter the old password and the new password twice, and click Apply. At the next log on, use the new
password.
Dual Image Configuration
Use the Dual Image Configuration page to name and change the next bootup image. The Dual Image
Configuration allows activating either of the stored images: Image1 or Image2. When one image is
activated, the other image serves as a backup; if Image1 either fails or does not boot, then the other
image can be activated.
To display the Dual Image Configuration page, click Maintenance > Dual Image Configuration.
Figure 10-17. Dual Image Configuration Page
Table 10-3. Dual Image Configuration Fields
Field Description
Image Name Select the image you want to perform an action on. You can activate the selected image, delete
it, or configure a description of it. Options are Image1 and Image2.
Active Image The currently active image.
Image Description Specify a description of the image selected in the Image Name field.
Image Version The software version associated with the active image.
