2-10
Status
MAC Table
MAC Table
The MAC Table page displays the MAC addresses configured for ports, and the MAC type including the
maximum entries supported an d the current number of entries learned. The default aging interval for
forwarding database is 300secs. Dynamically learned entries are removed if they are not updated within
the aging interval on a particular interface
To display the MAC Table page, click Status > MAC Table in the navigation pane.
Figure 2-6. MAC Table Page
Table 2-6. MAC Table Fields
Click the Refresh link above the page to re-display the page with current data from the switch.
Field Description
Maximum Entries
Supported
Displays a maximum of 8192 MAC address entries that can be learned on the switch.
Current Entries Displays the number of MAC address entries currently learned.
MAC Address The list of MAC addresses learned on a particular interface.
Source Port The source interface on which the particular MAC address has been learned.
CPU is a special source port used for internal management on the switch.
MAC Type Shows whether the MAC address is dynamically learned or whether this is a management address.
