HP Spectre x360 Maintenance And Service Guide

For use in country or region Spare part number For use in country or region Spare part number
In natural silver finish for use on all computers with model
numbers 13-4000 through 13-4099:
For use in the Netherlands 801508-B31
For use in Belgium 801508-A41 For use in Portugal 801508-131
For use in Canada 801508-DB1 For use in Russia 801508-251
For use in the Czech Republic
and Slovakia
801508-FL1 For use in Saudi Arabia 801508-171
For use in Denmark, Finland,
and Norway
801508-DH1 For use in South Korea 801508-AD1
For use in France 801508-051 For use in Spain 801508-071
For use in Germany 801508-041 For use in Turkey 801508-141
For use in Greece 801508-151 For use in the United Kingdom
and Singapore
801508-031
For use in Italy 801508-061 For use in the United States 801508-001
In natural silver finish for use only on HP Spectre Pro x360 Convertible PC computer models:
For use in Israel 801508-BB1 For use in Japan 801508-291
In natural silver finish for use only on HP Spectre x360 Convertible PC computer models with model numbers 13-4000
through 13-4099:
For use in Latin America 801508-161 For use in Switzerland 801508-BG1
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation,
turn the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 28), and then remove the following components:
a. Remove the battery (see Battery on page 29).
b. Remove the fan (see Fan on page 33).
c. Remove the system board (see System board on page 38).
Remove the keyboard:
1. Remove the 55 Phillips PM1.1×1.5 screws that secure the keyboard to the top cover from the locations
in the following illustration.
44 Chapter 5 Removal and replacement procedures

HP Spectre x360 Specifications

General

Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	15.6 \
Touch technology	Multi-touch
Native aspect ratio	16:9
Speakers manufacturer	Bang & Olufsen
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.0
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Power adapter depth	134.87 mm
Power adapter width	486.92 mm
Power adapter height	357.89 mm
Power adapter weight	3968.94 g
Battery capacity	64.5 Wh
Pointing device	Touchpad
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC adapter power	45 W
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-6200U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-6200 series
Processor socket	LGA 1356 (Socket B2)
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR2EY
Processor ARK ID	88193
Processor package size	42 X 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	247 mm
Width	378 mm
Height	16 mm
Weight	1823.44 g
