2 Technical specifications
General specifications
8.8 cm (3.47 in)Height (2U)
Dimensions 45.0 cm (17.99 in)Width
56.7 cm (22.3 in)Depth
17.2 kg (38 lb)Weight (base unit; no disk drives)
SFF disk drives: 24.9 kg (54.90 lb)
Weight (fully populated)
LFF disk drives: 27.2 kg (59.97 lb)
Power and environmental specifications
10°C to 35°C (50°F to 95°F)
Maximum rate of change is
10ºC/Hr (18ºF/Hr)
Operating
Temperature range (Temperature
ratings shown are for sea level. An
altitude rating of 1°C per 300 m
(1.8°F per 1,000 ft) to 3048 m
(10,000 ft) is applicable. No direct
sunlight allowed. The upper limit
might be limited by the type and
number of options installed.)
–40°C to 66°C (–40°F to 150°F)
Maximum rate of change is
20ºC/Hr (36ºF/Hr)
Shipping
10% to 90% relative humidity (Rh)
28ºC (82.4ºF) Maximum wet bulb
temperature non-condensing
Operating
Relative humidity (Non-operating
maximum humidity of 95% is based
on a temperature of 45°C (113°F).
Altitude maximum for storage cor-
responds to a pressure minimum of
70 KPa.)
5% to 95% relative humidity (Rh)Non-operating
3048 m (10,000 ft) This value
might be limited by the type and
number of options installed.
Operating
Altitude (Maximum allowable alti-
tude change rate is 457 m/min
(1500 ft/min))
9144 m (30,000 ft)Non-operating
100 to 240 VACRated input voltageInput power (Input Power and Heat
Dissipation specifications are max-
imum values and apply to worst-
case conditions at full rated power
supply load. The power/heat dissip-
ation for your installation will vary
depending on the equipment con-
figuration.)
50 to 60 HzRated input frequency
2.68 A at 115 VAC typical, 4 A
maximum
Rated input current
300 WInput power (max)
D2600/D2700 Disk Enclosure User Guide 21
