Figure 9 Configuration Example for HTTPS Connections Between P9000 Replication Manager and
IBM HTTP Server
Use the IBM HTTP Server httpd.conf settings file to configure IBM HTTP Server.
The following table describes authentication methods used between P9000 Replication Manager
and IBM HTTP Server.
Table 26 Authentication Methods Used Between Replication Manager and IBM HTTP Server
Authentication methodBeing authenticatedAuthentication
Server certificate (SSL)IBM HTTP ServerP9000 Replication Manager
Basic access authentication (HTTP)P9000 Replication ManagerIBM HTTP Server
When HTTP is used to connect P9000 Replication Manager and IBM HTTP Server, P9000 Replication
Manager cannot send the information necessary for performing basic access authentication.
An overview of the setup procedure for establishing HTTPS connections is shown in . All of the
steps indicated in Figure 10 (page 63) must be performed on all of the sites.
62 Setting Up the Environment When Linking with P9000 Replication Manager
