HP StorageWorks SN6000 Fibre Channel Switch QuickTools Switch Management User Guide 51
Zones/Security Group
Interop Mode Standard
Legacy Address Format None
Merge Auto Save If Enabled, any zoning updates from the fabric will be saved
in permanent (non-volatile) memory as well as temporary
memory. If Disabled, any zoning updates from the fabric will
be saved only in temporary memory and will be lost after a
switch reset.
Default Zone Enables or disables communication between ports and
devices not defined in the active zone set, or when there is
no active zone set.
Discard Inactive Automatically removes the previously active zone set when a
zone set is activated on a switch.
Implicit Hard Zoning Introduces hardware enforcement of zoning regardless of
type. All zones and all supported zone member types will
have hardware enforcement.
Security Auto Save Enable to automatically save security settings to permanent
memory on the switch.
Security Fabric Binding
Enabled
If Enabled, the expected domain ID of a switch is required
before the switch can be attached to the fabric.
Advanced Group
R_A_TOV Resource allocation timeout value (in milliseconds)
E_D_TOV Error detect timeout value (in milliseconds)
Number of Donor Groups Total number of donor port groups. A donor group is a set
of ports on a switch that can donate buffer credits to one
another.
Inactivity Timeout Number of minutes the switch waits before terminating an
idle command line interface session. Zero (0) disables the
time out threshold.
Interop Mode Standard
Legacy Address Format None
In-band Enabled In-band management status. Permits (True) or prevents
(False) a switch from being managed over an ISL.
Principal Switch If there is a domain ID conflict in the fabric, the switch with
the highest principal priority, or the principal switch, will
reassign any domain ID conflicts and establish the fabric.
Table 8 Switch data window fields (Continued)
Field Description
