Figure 7 SuperCapacitor module connector on RAID card
LEDs2SuperCapacitor connector1
4. Replace the cover and power up the HPE StoreOnce Backup system. Check the status of
the system on the Hardware page of the StoreOnce GUI. If this does not resolve the problem,
the associated RAID card may need replacing.
5. Use the StoreOnce GUI or StoreOnce CLI to check that the firmware on the new component
is correct. See Upgrading BIOS or hardware firmware (page 9).
NOTE: Note the output at command completion. It will advise if you need a system reboot
or a cold reboot to install the new firmware revision successfully.
24 RAID cache module and SuperCapacitor failures
