Disk enclosure configurable parts
This is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the
online source, use the feedback form to log the problem: http://partsurfer.hpe.com/
ContactUs.aspx.
The following table lists the replacement parts for the disk enclosure.
Table 2 Spares part numbers for the disk enclosure
Hot plug?Part numberDescriptionPart
Yes142258-004SPS-CORD AC PWR IEC RT APower cord
No663680-001SPS-ASSY D6000 DRAWER BRICK HDDDrawer*
Yes389015-001SPS-BLANK HD SLIMLN INTRHard disk blank
Yes663681-001SPS-BEZEL EAR RIGHT D6000Right bezel ear
Yes579229-001SPS-POWER SUPPLY 1200W PPower supply
No663679-001SPS-BD D6000 SAS IO MODULEIO module
No712430-001SPS-CHASSIS D6000 LCDLCD
Yes413996-001SPS-FAN SYSTEMFan
No689128-001SPS-ASSY D6000 POWER BLOCK w/POWERPower block*
Yes743405-001SPS-DRV HD 4TB 6G 7.2K 3.5 SAS MDL4 TB Hard disk
No717429-001SPS-CA EXT HYB MSAS HD TO MSASExternal SAS cable, server
to disk enclosure
No408765-001SPS-CA,EXT MINI SAS, 0.5MExternal SAS cable,
between drawers on disk
enclosure
IMPORTANT: * Drawer (663680-001) and Power Block (689128-001) parts must not be
replaced at the same time. Only replace one of these at a time and ensure the D6000 is powered
up for at least 5 minutes before replacing another component in order to preserve the D6000
system values stored in each drawer. See When replacing Drawer Assembly and Power Block
Assembly (page 26).
HPE StoreOnce 4900 disk enclosure 7
