Changing BIOS Settings Using the F10 Utility
1.
Turn on or restart the thin client.
2.
As soon as the thin client is turned on, press F10 when the monitor light turns green to enter the Setup
Utility.
NOTE: If you do not press F10 at the appropriate time, you must restart the thin client and again
press F10 when the F10=Setup message displays in the task bar at the bottom of the screen. When
the F10 POST Screen display is set to zero seconds, it may be necessary to press and hold F10 on
the keyboard, then power on the thin client.
3.
The Setup Utility screen is divided into five menu headings and five task actions.
The Menu Headings are:
●
System Information
●
Standard CMOS Features
●
Advanced BIOS Features
●
Integrated Peripherals
●
Power Management Setup
The Task Actions are:
●
Load Factory Defaults
●
Set Administrative Password
●
Set User Password
●
Save & Exit Setup
●
Exit without Saving
Use the arrow keys (up and down or left and right) to select the appropriate heading, then press
Enter. To return to the Setup Utility menu, press Esc key.
4. To apply and save changes, select Exit Setup & Save.
If you have made changes that you do not want applied, select Exit without Saving.
To reset to original factory settings, select Load Factory Defaults.
CAUTION: Do NOT turn the thin client power Off while the ROM is saving the Setup (F10) changes
because the CMOS could become corrupted. It is safe to turn off the computer only after exiting the F10
Setup screen.
Table 2-1 Setup (F10) Utility Main Menu
Heading Table
System Information
Setup Utility—System Information on page 7
Standard CMOS Features
Setup Utility—Standard CMOS Features on page 8
Advanced BIOS Features
Setup Utility—Advanced BIOS Features on page 8
6Chapter 2 BIOS Settings, (F10) Utility ENWW
