HP TOUCHSMART 9100 User Manual

Welcome 13
Computer Stand
The HP TouchSmart 9100 Business PC is shipped with the computer stand collapsed against the back of
the computer. To assure that the computer is in a stable position on your desktop, pull the computer stand
open until it snaps into place. Then, if you want to change the angle of the HP TouchSmart 9100, hold
each side of the computer, and tilt it (the monitor moves forward; the stand stays in place) to an angle of
between 5 degrees and 40 degrees from the vertical.
Computer Swivel
The computer allows a usable range of motion with the swivel feature.
CAUTION: Make sure the angle of the computer is at least 5 degrees from the vertical;
otherwise the computer will be unstable and could fall over.
CAUTION: The computer stand stays in place as you increase the angle; the computer moves
forward. Take care that the computer screen does not move off the table.
40°
max
5° min.

HP TOUCHSMART 9100 Specifications

General

Processor cache	2 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor frequency	2.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor front side bus	800 MHz
Chassis type	All-in-One
Display included	Yes
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Graphics card family	NVIDIA
Floppy drive installed	No
Parallel ports quantity	0
Maximum graphics card memory	- MB
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Number of processors installed	1
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Discrete graphics card model	NVIDIA GeForce 200
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	5
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Country of origin	China

Weight and Dimensions

Depth (with stand)	72 mm
Width (with stand)	579 mm
Height (with stand)	447 mm
Weight (with stand)	11500 g
