Item Component Function
(9) Wireless light
●
Blue: An integrated wireless device, such as a
WLAN device and/or a Bluetooth device, is
turned on.
●
Amber: All wireless devices are turned off.
*This table describes factory settings. For information about changing factory settings, refer to the user guides located in
Help and Support.
Left-side components
Item Component Function
(1) Power connector Connects an AC adapter.
(2) ExpressCard slot Supports optional ExpressCard/34 cards.
(3) Digital Media Slot Supports the following optional digital card formats:
Secure Digital (SD) Memory Card, MultiMediaCard
(MMC), Memory Stick (MS), Memory Stick Pro (MSP),
xD-Picture Card (XD), xD-Picture Card (XD) Type M.
(4) Digital Media Slot light On: A digital card is being accessed.
(5) Optical drive Reads optical discs and, on select models, also writes
to optical discs.
(6) Optical light Blinking: The optical drive is being accessed.
10 Chapter 2 External component identification
