Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head width
Black 6 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) Two captive screws (secured with C-clips) that secure the hard drive cover to the computer
(2) Two captive screws (secured with C-clips) that secure the memory module compartment cover to
the computer
(3) One captive screw (secured with a C-clip) that secures the WLAN module compartment cover to
the computer
(4) One captive screw (secured with a C-clip) that secures the display cable cover to the computer
Phillips PM2.0×5.0 captive screw 89
