HP TOUCHSMART TX2 User Manual

Bluetooth module
Description Spare part number
Bluetooth module 483113-001
Bluetooth module cable 487697-001
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power cord.
4. Remove the battery (see
Battery on page 38).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 40)
b. Optical drive (see
Optical drive on page 43)
c. Keyboard (see
Keyboard on page 49)
d. Switch cover (see
Switch cover on page 51)
e. Display assembly (see
Display assembly on page 53)
f. Top cover (see
Top cover on page 56)
Remove the Bluetooth module:
1. Disconnect the Bluetooth module cable (1) from the system board.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the Bluetooth module to the system
board.
60 Chapter 4 Removal and replacement procedures

HP TOUCHSMART TX2 Specifications

General

RAM	4 GB DDR2
Resolution	1280 x 800
Graphics	ATI Radeon HD 3200 Graphics
Operating System	Windows Vista Home Premium
Battery	6-cell Lithium-Ion Battery
Wireless	802.11a/b/g/n
Bluetooth	Bluetooth 2.0
Storage	320GB HDD
Display	12.1" WXGA High-Definition HP BrightView Display
Optical Drive	LightScribe SuperMulti 8X DVD±RW with Double Layer Support
Webcam	HP Webcam
