3. Remove the display release hook assembly (3).
NOTE: The display release hook assemblies are included with the base enclosure
spare part kit.
4. Disconnect the power switch board cable (1) from the system board.
5. Remove the power switch board (2) and power switch actuator (3) from the base enclosure.
Reverse this procedure to install the power switch assembly.
Component replacement procedures 59
