Hard drive

NOTE: The hard drive spare part kit includes a hard drive bracket, hard drive connector, and Mylar

cover.

Description Spare part number

500-GB, 7200-rpm 634934-001 or

574875-001

320-GB, 7200-rpm 603783-001

320-GB, 5400-rpm 622643-001

160-GB, 7200-rpm 579045-001

Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector, and

hard drive screws)

497744-001

Before removing the hard drive, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power cord.

4. Remove the battery (see

Battery on page 38).

Remove the hard drive:

1. Position the computer with the front toward you.

2. Loosen the two Phillips PM2.0×5.0 captive screws (1) that secure the hard drive cover to

the computer.

3. Lift the left side of the hard drive cover (2) and swing it to right.

40 Chapter 4 Removal and replacement procedures
