System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part
number
System board for use in HP Pavilion x360 models equipped with:
Intel Core M3-6Y30C processor and a Windows 10 operating system 827663-601
Intel Core M3-6Y30C processor and a non-Windows operating system 827663-001
Intel CoreT M-5Y10C processor and the Windows 8.1 Standard operating system 809560-501
Intel CoreT M-5Y10C processor and a non-Windows 8 operating system 809560-001
Intel Pentium N3700 processor and the Windows 10 operating system 828895-601
Intel Pentium N3700 processor and a non-Windows operating system 828895-001
Intel Pentium N3700 processor and the Windows 8.1 Standard operating system 809557-501
Intel Pentium N3700 processor and the Windows 7 operating system 809557-001
Intel Celeron N3050 processor and the Windows 10 operating system 829211-601
Intel Celeron N3050 processor and a non-Windows operating system 829211-001
Intel Celeron N3050 processor and the Windows 8.1 Standard operating system 809556-501
Intel Celeron N3050 processor and a non-Windows 8 operating system 809556-001
System board for use in HP x360 310 G2 models equipped with:
Intel Pentium N3700 processor and the Windows 8.1 or Windows 10 operating system 824146-601
Intel Pentium N3700 processor and a non-Windows operating system 824146-001
Intel Celeron N3050 processor and the Windows 8.1 or Windows 10 operating system 824144-601
Intel Celeron N3050 processor and a non-Windows operating system 824144-001
Before removing the system board, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the top cover (see Top cover on page 29).
Component replacement procedures 43
