TouchPad
Description Spare part number
TouchPad not spared
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Top cover on page 29).
5. Remove the battery (see Battery on page 53).
Remove the TouchPad:
1. Position the top cover upside down.
2. Remove the six broadhead Phillips PM2.0×2.0 screws (1) that secure the touchpad and the bracket.
3. Lift the bracket o the top cover (2).
4. Lift the touchpad o the computer (3).
Reverse this procedure to install the TouchPad.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
