Battery
Description Spare part number
2-cell, 32-Wh, 4.2-Ah, Li-ion battery for use in all models 796355-005
3-cell, 48-Wh, 4.21-Ah, Li-ion battery for use in HP x360 310 G2 models 817184-005
Before removing the battery, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the top cover (see Top cover on page 29).
Remove the battery:
WARNING! To reduce potential safety issues, use only the battery provided with the computer, a
replacement battery provided by HP, or a compatible battery purchased from HP.
1. Disconnect the battery cable from the system board (1).
2. Disconnect the speaker cable from the system board (2), lift the tape that secures the cable to the
battery (3), and remove the cable from atop the battery (4)
3. Disconnect the USB/card reader board cable from the system board (5) and the USB/card reader board
(6), and then (if replacing the battery) remove the cable from atop the battery (7).
NOTE: If replacing the battery, be sure to attach the at USB/card reader cable to the top of the new
battery.
4. Remove the four Phillips PM2.5×4.0 screws (1) that secure the battery to the computer.
Component replacement procedures 53
