HP x360 310 G2 User Manual

6. Run a plastic, non-marking tool around the seam to disengage the top cover from the computer.
Separate the top cover from the computer by separating and lifting up at the seam on the left side (1),
top (2), and right side (3), far enough to access the keyboard and touchpad connectors on the system
board.
NOTE: You can use a plastic, non-marking tool inserted in the seam to disengage the top cover.
NOTE: When you lift the top cover, the keyboard cable and the touchpad cable are connected to the
system board. Be sure not to pull the cables loose when lifting the bottom cover.
7. Disconnect the touchpad cable (1) and the keyboard cable (2) from the system board, and then remove
the top cover from the computer (3).
Reverse this procedure to install the top cover.
Component replacement procedures 31

HP x360 310 G2 Specifications

General

Graphics	Intel HD Graphics
Processor	Intel Celeron N3060
RAM	4 GB DDR3L
Storage	500 GB HDD
Display	11.6-inch HD (1366 x 768)
Operating System	Windows 10 Home
Battery	3-cell Li-ion
Ports	HDMI, headphone/microphone combo
Wireless	Bluetooth 4.0
