DIMM installation order

Install DIMMs in this order.

NOTE: If you install DIMMs of dierent sizes, load them in order of size, starting with largest and nishing

with the smallest (largest in DIMM 1, smallest in last loaded DIMM).

Component replacement guidelines 45
