4) Lift the connector up and away from the PCB.
Connector repair
This procedure includes HDMI, Display Port, Mini Display Port, USB-C and USB-A connectors.
The connectors are on the main board (board part number 7ZB.A3B01.0010).
The connector identifiers are as follows:
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 12.
