4 Removal and replacement procedures
Adherence to the procedures and precautions described in this chapter is essential for proper service. After
completing all necessary removal and replacement procedures, run the Diagnostics utility to verify that all
components operate properly.
NOTE: Not all features listed in this guide are available on all computers.
Preparation for disassembly
WARNING! Voltage is always present on the system board when the computer is plugged into an active
AC outlet. To avoid possible personal injury and damage to the equipment the power cord should be
disconnected from the computer and/or the AC outlet before opening the computer.
See Routine care, SATA drive guidelines, and disassembly preparation on page 9 for initial safety procedures.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as compact discs or USB ash drives, from the computer.
3. Turn o the computer properly through the operating system, then turn o any external devices.
4. Disconnect the power cord from the AC outlet and disconnect any external devices.
CAUTION: Turn o the computer before disconnecting any cables.
Regardless of the power-on state, voltage is always present on the system board as long as the system
is plugged into an active AC outlet. In some systems the cooling fans are on even when the computer is
in the “Standby,” or “Suspend” modes. The power cord should always be disconnected before servicing
a unit.
NOTE: During disassembly, label each cable as you remove it, noting its position and routing. Keep all
screws with the removed components.
Preparation for disassembly 15

HP Z4 G4 Specifications

General

Tcase	65 °C
Bus type	QPI
Stepping	U0
Processor cache	8.25 MB
Processor cores	6
Processor model	W-2133
System bus rate	0 GT/s
Processor socket	LGA 2066 (Socket R4)
Processor threads	12
Processor codename	Skylake
Processor frequency	3.6 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x4, 1x8
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866, 2133, 2400, 2666 MHz
Memory bandwidth supported by processor (max)	85.3 GB/s
Maximum internal memory supported by processor	512 GB
Operating system installed	Windows 10 Pro for Workstations
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2666 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	2 x 8 GB
HDD speed	7200 RPM
RAID levels	0, 1, 5, 10
HDD capacity	1000 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
HDD interface	SATA
SSD interface	PCI Express
Storage media	HDD+SSD
Optical drive type	DVD-RW
Card reader integrated	No
Total storage capacity	1256 GB
Discrete graphics card model	Not available
Power supply	1000 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	10
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Sustainability certificates	ENERGY STAR
Chassis type	Tower
Product color	Black
Country of origin	China
Intel® vPro™ Platform Eligibility	-
Audio chip	Realtek HD ALC221
Product type	Workstation
Motherboard chipset	Intel® C422
Scalability	1S
Processor code	SR3LL
Processor ARK ID	125040
Processor package size	45 x 52.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	386 mm
Weight	10200 g
