Installing the system board
To install the system board:
1. Insert the system board with the rear chassis side of the board tilted slightly downward.
2. Push back on the board while maintaining downward pressure on the board to clear the release
mechanism. The latch should click into place.
3. Reinstall all removed components and cables. (Refer to
Power connections on page 90 to identify
power cables.)
ENWW Removing and installing components 133
