Front panel components
The following figure shows the front panel of a typical workstation configuration.
Figure 1-4 Front panel
Table 1-2 Front panel connectors
Item Symbol Description Item Symbol Description
1 Optical drive manual eject 6 Headphone connector
2 Optical drive eject button 7 Microphone connector
3 Power button 8 1394a connector (optional and plugged
unless configured)
4 Hard drive activity light 9 Optical drive activity light
5 USB 2.0 ports (2) 10 Optical drive
6 Chapter 1 Product overview ENWW
