Component cablingComponent cabling Cable part numberCable part number
Four-bay non-hot-plug drive cablingFour-bay non-hot-plug drive cabling —
Four-bay non-hot-plug drive: Onboard SATA cables P63969-001
Four-bay non-hot-plug drive: Type-p controller converter cable P64334-001
Serial port cablingSerial port cabling P63693-001
Miscellaneous cablingMiscellaneous cabling —
Ambient temperature sensor cable P65284-001
Fan cable P63537-001
4-pin processor power cable P64322-001
4-pin PDB to system board power cable P63697-001
Internal cabling managementInternal cabling management
ItemItem DescriptionDescription
1 Cable clip
2 Metal tab
3 Metal tab
4 Cable clamp
5 Cable tie secures the following cables:
Fan cable
CPU power cable
System power cable
Drive power cable
